◆可选带以下附件 optional with the accessories as follows: .
→滤波电容(电容值由客户选定，一般为0.22μf或0.33μf)
→suppression capacitor (commonly 0.22or 0.33μf)

→机械耐久寿命 mechanical life endurance≥1e5
→电气耐久寿命 electrical life endurance≥5e4
→最大冲击电流 max. inrush current at 250v60a
→最大冲击电流 max. inrush current at 127v90a
→最大电流 max. current at 42vd.c30a
→最大电流 max. current at 24vd.c40a
→接触电阻 contact resistance≤30m ohm
→绝缘电阻 insulation resistance≥7m ohm
→基本介电强 度dielectric strength of function1500v
→加强介电强度 dielectric strength of reinforced3000v
→环境温度 ambient temperature0°c~55°c
→阻燃等级 flammabilityul 94v-0
→防护等级 protection typeip50
→适用于ii类防护器具 suitable for appliances of protection class ii

◆输入端 input side:
→螺钉端子 screw terminals m3.5
◆输出端 output side:

→插片端子 plug-in terminals 4.8×0.8mm

→焊接端子 plug-in terminals 4.8×0.8mm

→电容插片端子 plug-in terminals for capacitor 2.8×0.8mm
★本产品荣获实用新型专利，专利号：zl202020005964.6
★utility model patented with the no. is zl202020005964.6
