产品描述product description
◆fa7-10d系列是一款通用型的扳机开关，应用于对防尘要求较低的手持式电动工具和园林工具，如：搅拌器、电动钉枪、电圆锯、打草机、电链锯、电动割草机、电动扫雪机等。
◆fa7-10d series are general type trigger switch, for used in portable power-tools and gardening tools such as electric mixers, electric nailers, grass trimmers, circular saws, electric chain saws, electric lawnmowers, electric snowthrowers, etc.
产品特征features
◆可选带以下锁定类型 optional with following lock types:
→无锁定 no lock
→闭合锁定 lock-on
→断开锁定 lock-off
技术数据technical data
→机械耐久寿命 mechanical life endurance≥1e5
→电气耐久寿命 electrical life endurance≥5e4
→最大冲击电流 max. inrush current at 250v90a
→最大冲击电流 max. inrush current at 125v108a
→接触电阻 contact resistance≤30m ohm
→绝缘电阻 insulation resistance≥7m ohm
→基本介电强度 dielectric strength of function1500v
→加强介电强度 dielectric strength of reinforced3000v
→环境温度 ambient temperature0°c~55°c
→阻燃等级 flammabilityul 94v-0
→防护等级 protection typeip40
→适用于ii类防护器具 suitable for appliances of protection class ii
端子类型terminals
◆输入端/输出端 input side/output side:
→接线柱端子 pillar terminals φ=3.5mm
电气参数和认证 electric rating and certification
